DragonRF

The benchmark RF Test Solution for 4G and  Beyond

Highlights and Key Features

Highlights

  • High performance RF test capability
  • New levels of manufacturing test efficiencies

 Key Features

  • Configurable with 16 or 32 Universal RF ports per module with an optional port to pin expander, doubling the number of RF ports to 64 pins
  • 6 GHz RF modulated source and 8 GHz RF measure
  • <1 ms RF settling time on level and frequency change
  • Quad site and octal site RF source with single and dual synthesizer respectively
  • Up to 8 receiver paths each with an analog bandwidth exceeding 200 MHz for octal site parallel RF measurements
  • Each receiver is connected to a digitizer with up to 400Msps, or 16-bit
  • Real time Dynamic Range Enhancer (DRE) per RF measure path
  • Compact footprint RF generators
  • Industry-leading source muxing flexibility
  • Latest RF Synthesizer technology
  • Cross-platform test system software: Unison
  • Available across a range of Cohu test platforms thus ensuring the most cost-effective test capability no matter the end application

Benefits

  • Extensive suite of capabilities designed to provide the lowest cost of test without any compromise in RF test performance
  • Innovative flexible architecture enables lower priced configurations without trade off in test coverage or test time

Devices and Applications

DragonRF is designed to support the latest wireless communication standards whether it’s an RF Power Amplifier or a RF SOC application. Leveraging the extensive Cohu wireless modulation and demodulation library, DragonRF supports the complete set of tools to test cellular GSM, Edge, GPRS, HSDPA, HSUPA, CDMA, LTE and connectivity devices including BT, BT EDR, BT4.0, GPS, 802.11 a/b/g/n/ac/p and other emerging standards.

DragonRF provides up to 200 MHz IF bandwidth, enabling whole spectrum capture by receiver to support ever-increasing bandwidth in the newer wireless communication standards. Combined with leading Signal-to-Noise Ratio performance and optimized algorithm, DragonRF achieves the fastest and most accurate EVM measurement to test the comprehensive performance of today’s complex RF devices with shortest test time.

Universal Port with Configuration Flexibility

DragonRF is designed with universal vector port architecture that delivers the required level of performance with flexible configuration to match the rapidly evolving device testing needs. Each DragonRF can be configured with 16, or 32 universal vector ports.

DragonRF can also be configured with 1, 2, 3, or 4 RF synthesizers to provide octal site modulated RF stimulus to the devices, and with 2, 4, or 8 RF measure paths for true parallel octal site RF measurements.

Industry Leading Settling Times

DragonRF uses the latest technology in RF synthesizer and RF control circuitry in its design. The Rohde and Schwartz SGS100 RF source is used as the synthesizer in DragonRF, utilizes the latest synthesizer architecture and software.

Combined with all CMOS RF paths in the new DragonRF module, DragonRF provides fast level and frequency settling time to 0.05 dB less than 1ms, greatly enhancing the test throughput, and lowering the cost of test.

RF Auto Calibration

DragonRF’s fully automated calibration process allows greater tester up-time and reduces operator-induced errors and variations. The DragonRF Auto Calibration kit offers a single self-contained calibration unit that provides:

  • Calibration of RF source, scalar measure, noise, and S-parameter measure
  • Internal R&S power sensors
  • NIST traceable integrated RF power meter and noise source
  • Factory calibrated RF Autocal fixture

Multisite Software

The Unison software environment provides users with fast single site program development, instantaneous multi-site testing capability, and test IP that can be transferred from device to device. Unison features cutting-edge productivity tools that accelerate development and debug time, shortening the time to high volume production for current and next generation products.

Better Yield with Dynamic Range Enhancer

Every RF receiver is equipped with real time Dynamic Range Enhancer (DRE) with embedded DSP capability. With DRE enabled, DragonRF provides more than 30 dB dynamic range, which is critical for RF measurements, especially ACPR. This enables faster test time, rapid correlation between ATE and bench-top instrument, and it improves yield with extra margins above the noise floor.

More Information

Raven

The benchmark RF Test Solution for 5G, Ku-band and  Beyond

Highlights and Key Features

Highlights

  • High performance RF test capability
  • Highest levels of manufacturing test efficiencies

 Key Features

  • Configurable with 8 Universal RF ports per brick, up to 2 bricks per system
  • 14.75 GHz RF modulable source and 14.75 GHz RF measure
  • <1 ms RF settling time on level and frequency change
  • Quad site and octal site RF source with single and dual synthesizer respectively
  • Up to 4 receiver paths per brick with an analog bandwidth exceeding 1 GHz for quad site parallel RF measurements
  • Real time Dynamic Range Enhancer (DRE) per RF measure path
  • Compact footprint RF generators
  • Industry-leading source muxing flexibility
  • Latest RF Synthesizer technology
  • Cross-platform test system software: Unison
  • Available across a range of Cohu test platforms thus ensuring the most cost-effective test capability no matter the end application

Benefits

  • Extensive suite of capabilities designed to provide the lowest cost of test without any compromise in RF test performance
  • Innovative flexible architecture enables lower priced configurations without trade off in test coverage or test time

Devices and Applications

Raven is designed to support the latest wireless communication standards and future requirements whether it’s an RF Power Amplifier or a RF SOC application. Leveraging the extensive Cohu wireless modulation and demodulation library, supporting the complete set of tools to test cellular GSM, Edge, GPRS, HSDPA, HSUPA, CDMA, LTE and connectivity devices including BT, BT EDR, BT4.0, GPS, 802.11 a/b/g/n/ac/p and other emerging standards.

Raven provides greater than 1 GHz IF bandwidth enabling whole spectrum capture by receiver to support ever increasing bandwidth in the newer wireless communication standards. Combining with leading SNR performance and optimized algorithm, Raven achieves the fastest and accurate EVM measurement to test the comprehensive performance of the most complicated devices with lowest test time.

Universal Port with Configuration Flexibility

Raven is designed with universal vector port architecture that delivers the required level of performance with flexible configuration to match the customers’ device testing needs. Each Raven can be configured with 8, or 16 universal vector ports.

Industry Leading Settling Times

Raven uses the latest technology in RF synthesizer and RF control circuitry in its design. The R&S SGU100 RF source is used as the synthesizer in Raven, which utilized the latest synthesizer architecture and software.

Combined with all CMOS RF paths in the Raven module, Raven provides fast level and frequency settling time to 0.05 dB less than 1ms, greatly enhancing the test throughput, and lowering the cost of test.

RF Auto Calibration

Raven fully automated calibration process allow greater tester up-time and reduces operator induced error and variations. The Raven Auto Calibration kit offers a single self-contained calibration until that provides:

  • Calibration of RF source, scalar measure, noise, and S-parameter measure
  • Internal R&S power sensors
  • NIST traceable integrated RF power meter and noise source
  • Factory calibrated RF Autocal fixture

Multisite Software

The Unison software environment provides users with fast single site program development, instantaneous multi-site testing capability, and test IP that can be transferred from device to device. Unison features cutting-edge productivity tools that accelerate development and debug time, shortening the time to high volume production for current and next generation products.

Better Yield with Dynamic Range Enhancer

Every RF receiver is equipped with real time Dynamic Range Enhancer (DRE) with embedded DSP capability. With DRE enabled, DragonRF provides more than 30 dB dynamic range, which is critical for RF measurements, especially ACPR. This enables faster test time, rapid correlation between ATE and bench-top instrument, and it improves yield with extra margins above the noise floor.

Nighthawk

An ATE Paradigm Shift in RF Connectivity Test

Highlights and Key Features

Highlights

  • Ultra compact RF instrument
  • For the complete range of RF connectivity applications; WLAN, Bluetooth, Zigbee, GPS, DVB, FM and more

Key Features

  • Highest throughput enabled by real time processing, high speed PCI Express data transfer and full parallel source and measure
  • Benchtop instrument design and calibration strategy enables portability between Cohu systems typically less than 30 minutes
  • Annual calibration cycles
  • Built-in low jitter clock and baseband signaling

Benefits

  • Lower cost of test by over 50% compared to traditional competitive solutions
  • Widest IF bandwidth in the industry, allowing for fast and accurate testing of all existing standards and the newly emerging 802.11ac devices
  • Powerful embedded DSP processing to enhance dynamic range and produce the fastest throughput
  • Ultracompact RF system (the size of a laptop), which can easily upgrade any Diamond10 and Diamondx test system in the field in typically 30 minutes
  • Lowest annual operating cost due to a calibration strategy which eliminates costly hardware and improves test cell operational efficiency

Nighthawk a New Paradigm for RF ATE

Connectivity semiconductors are high volume, price sensitive ICs used in a diverse and growing portfolio of consumer products. Future growth challenges include ever increasing performance requirements only to be matched competitive margin pressure.

Faced with margin pressures, the only option is to stretch large old technology test systems into massive multi-site configurations. However, massive multi-site is not a true cost down alternative as those solutions raise capital cost, over time lowers capital utilization, complicates operational process, while extending time to market.  Nighthawk, the result of 30 years of RF/DSP test experience, is a true paradigm shift improving on every aspect of production test cost.

Unique Approach for RF Connectivity Test Challenges

Nighthawk CT sets a new benchmark for low cost Connectivity RF test. The culmination of 30 years RF/DSP experience is integrated into a small high-performance RF test extension compatible with Diamond and X-Series platforms.

Nighthawk’s design leverages the same RF semiconductor innovations that enable today’s consumer connectivity solutions. The goal is to match the ever shrinking semiconductor ASP with a high performance, low-priced RF test system. Nighthawk accomplishes this by embedding all required source, measure and DSP modules into a small air-cooled package. This not only reduces the cost of the RF system, but replaces expensive tester instrumentation. The result is a product with benchtop portability that has the performance of high-volume manufacturing ATE.

Nighthawk provides true quad site parallel transceiver test capability at a fraction of the cost compared to traditional test systems. In addition, all popular connectivity modulation standards are included in the system price.

Simple to Install, Easy to Program

Nighthawk’s test performance is among the best in the industry with full coverage for all connectivity bands and new features optimizing both test development and test time. Any Diamond10 or Diamondx teste system can be easily upgraded to full RF capability within 30 minutes. Additionally, each platform can support two Nighthawk modules providing eight sources, eight receivers and eight digitizers for outstanding throughput in octal site mode. Dual configurations can also simultaneously test two different connectivity standards.

More Information

Kestrel

Radar Test Solution

Highlights and Key Features

  • Simple installation with no system modifications required
  • Supported on X-Series test systems
  • Proven solution for stringent automotive applications
  • Annual calibration cycles
  • Wide range of source and measure levels

Benefits

  • Easily transferable from system to system
  • Provides test solution for both Q-band and E-band in a single testhead mounted interface
  • Customer calibration and verification available ensures standards traceability is maintained

Devices and Applications

Kestrel is designed to meet the testing requirements of automotive radar systems. The test head mounted instrument can be used with the  RF16 sub-systems. Capability to test both Q-band and E-band devices enables flexibility of production device mix and maximizes system throughput.  Although designed primarily for automotive radar, the instrument supports Q-band frequencies from 38GHz to 41GHz and E-band 76GHz to 81GHz making it an excellent choice for a number of other applications.

XRF Subsystem

RF capability of the X-Series Platform

Highlights and Key Features

Highlights

  • Enable the lowest cost system configurations
  • Instrument density and channel granularity allow test systems to be tightly configured to match device requirements

Key Feature

  • RF16 Port
  • RF SMATE Generator
  • Low Jitter Clock Generator
  • Scalar Frequency Extender
  • RF Auto Calibration

Benefits

  • Dynamic Range >90 db using the Dynamic Range Enhancement (DRE) feature
  • Faster test time
  • Faster correlation to bench data
  • Improved yield
  • Wide IF Bandwidth 100Mhz enables single capture acquisition for faster test time
  • Faster test times and throughput with Real-time Digital Signal Processing with FPGA based solution
  • Universal port performance available at all DUT I/O pins with 16 Bi-directional Vector Capable Ports
  • Fully automated calibration process
